Best Solar Panels For A Zamp Ready Trailer And How To Use Third-Party Panels
If you have an RV, travel trailer like an Airstream or a fifth wheel with a Zamp solar port, you can connect solar panels through this port to your 12V RV house batteries.
Zamp makes and sells its proprietary solar panels, which comes in four different sizes: 45W, 90W, 140W, and 230W, you can click on either to view it on Amazon.
Related Post: Solar Panels For A Prewired Furrion Solar Port
How big of a solar panel you need to charge your RV batteries depend on a couple of factors, and if you’re not sure what you need I recommend reading my post on this topic, click here to view it.
These Zamp panels are made in the United States with high-quality parts and are compatible out of the box with the Zamp solar port. For this reason, they’re the best solar panels for a Zamp ready trailer.
Zamp Solar 140-Watt Portable Solar Kit
But you’re not limited to using Zamp solar panels with a Zamp solar port, and that’s what we’ll focus on down below – How do you connect third-party panels to this Zamp solar port?
Note that Zamp recommends using only Zamp solar panels with their solar ports, so connecting any panels down below is done at your own risk and you need to check that the port and wiring on your specific RV or camper can handle the output of the panel you connect.
Best Solar Panels To Use With The Zamp Solar Port
Note: Scroll left/right on small screens to see the whole table.
Here are my solar panel recommendations for the prewired Zamp solar port, the links below will take you to the product page on Amazon.com. Before you connect any panel, make sure that the polarity is correct, meaning that positive is going to positive, and negative to negative.
Renogy 100 Watt Eclipse Monocrystalline Solar Suitcase – The Renogy Eclipse panel is my top recommendation. It’s a very portable and efficient solar panel that will charge your RV batteries quickly. It comes with a built-in charge controller that tells you state of charge and amperages, a kickstand, and includes a carrying bag for easy transport. Requires the iGreely MC4 To SAE 10AWG to make the connection.
Zamp Solar 140-Watt Portable Charger Kit – The Zamp solar panels are good choices since they’re made in the US and come with a 25-year warranty. They’re high-quality panels and have a better kickstand than the others. Compatible with the Zamp solar port right out of the box. They’re also available in 45W, 90W, and 230W. These don’t require any additional adapters.
HQST 100 Watt 12 Volt – Another great option, by a company called HQST. Requires the iGreely MC4 To SAE 10AWG to make the connection to the port on your camper.
Renogy 100W Portable Kit – I have two of these, and they’re very similar to the Eclipse panels above. Kickstand, charge controller, carrying case. Easy to set up and transport. Requires the iGreely MC4 To SAE 10AWG to make the connection.
What To Think About When Using The Zamp Solar Port
The main thing you must know about the Zamp solar port is the type and its polarity. Polarity means which side is positive and which is negative. The plug used by Zamp is called an SAE connector.
This image from teardrop-trailers.vanillacommunity.com shows it in an easy to understand way.
When you plug a solar panel into this port, you should be able to follow the positive wire going all the way from the solar panel, to the positive terminal on the Zamp port. Let’s call the positive terminal on the Zamp port male and the negative terminal female.
It’s very important that the polarity is correct when you plug it into the Zamp port. It’s easy to follow the wire and make sure it’s correct.
Now, let’s take a look at the adapter we can use to plug third-party solar panels into this port.
The Adapter You Need To Connect A Third-Party Solar Panel To A Zamp Ready Solar Port
What we’re looking for is an MC4 to SAE adapter, like the iGreely MC4 To SAE 10AWG.
This adapter comes with a small SAE polarity switch adapter, so you can switch the polarity. We’re going to use this little adapter to make the correct connection (unless your solar panel has a negative male connector and a positive female connector).
Most solar panels are shipped with MC4 connectors and based on my experience, it’s more common that the solar panel has a positive male MC4 connector and a negative female MC4 connector (every panel I recommend down below do).
Related Post: How Big Of A Solar Panel Do I Need To Recharge RV Batteries?
That means that this adapter wouldn’t be compatible if you only look at the wire colors, but we can still use it even if the colors of the wire is wrong, as long as we follow the positive/negative wire and make sure it’s right when we plug it into the Zamp solar port.
So, let’s say we have one of the panels I recommend down below, with a positive male MC4 connector, and a negative female MC4 connector.
We’ll plug the positive (red) male MC4 connector from the solar panel into the female MC4 connector on the adapter (the black wire). Then we’ll plug the negative (black) female connector into the red male MC4 connector on the adapter. It feels wrong to connect the wrong colors, but this is how we’ll have to do it.
Now you’ll have the positive wire from the solar panel going through the adapter, to the male side on the SAE plug on the other side of the adapter. Now we need to reverse that polarity, so we’ll use the little SAE adapter included with the iGreely adapter. Now the positive wire from the panel ends up with an SAE female, which is what we need for the Zamp solar port.
Remember, the male SAE on the Zamp port is positive. The female SAE on the Zamp port is negative. When using the solar panels below, there will only be one way to connect the MC4 connectors, but you do have to use the reverse polarity adapter with the iGreely adapter before plugging it into the Zamp port.
What To Think About When Choosing A Solar Panel
I haven’t found any information about the size of the fuse or wires on the Zamp solar port between the port and the batteries, and it might depend on the trailer manufacturer, so I recommend contacting the trailer manufacturer or read the manual to find out what the amperage limit is for the port. This product page for the 230W panel states that it’s compatible with Zamp solar ports and that it comes with a 15A charge controller, but you should still check to be sure the port and wiring in your specific trailer can handle it.
You need to choose a solar panel with a solar charge controller built-in or buy a charge controller separately. The Zamp solar port is a direct connection to the RV batteries, so any solar panel that isn’t a trickle-charger should be used with a charge controller that protects the batteries from overcharging.
The panels I recommend down above come with a charge controller so you don’t have to do any additional wiring on most.
How Long Will It Take To Recharge My RV Batteries?
This is a question that’s hard to answer in one sentence without knowing the size of your batteries and solar panel. I have written a post that goes into this and how you can calculate it, click here to view that post.
Are There SAE/MC4 Extension Cables?
Yes, there are. The Ovitar 16AWG 12Ft Extension Cable (click to view on Amazon) is an example.
I use MC4 extension cables, and you might want to do that as well if you choose a panel with MC4 connectors. I recommend WindyNation MC4 extension cables that come in different sizes and lengths.
Will A Solar Panel Power The Outlets In My RV Camper?
A 12V solar panel connected to your trailer batteries will recharge these batteries, but won’t provide 120V AC power to your outlets.
To use your outlets, you’ll need to use an inverter that changes the 12V DC power to 12V AC power. An example of an inverter like that is the KRIËGER 1100 Watt 12V Power Inverter that has two AC outlets.
You can wire this inverter to your batteries, then plug your camper into one of the outlets with a 15A to 30A adapter, or a 15A to 50A adapter depending on the size of the electrical system in your camper.
What If My Trailer Has A Furrion Solar Port?
I have written a post about using the Furrion solar port, click here to view it.
Please leave a comment down below with any questions you might have.
Wonderful article Jesse! Thank you! I have a question that I am hoping you can help me with. We are looking to purchase the 200watt portable renogy panels and also use the ZAMP port. Would the IGreely solar panel to SAE Adapter 10AWG work with this larger watt panel? Or would I need a 12AWG adapter?
https://www.renogy.com/200-watt-eclipse-monocrystalline-solar-suitcase
Thank you Jesse for any help!
Sean O.
Hi,
The lower the gauge, the better, so 10 AWG will be the best option between the two for a 200W panel.
Hi, Jesse – Along those lines… the iGreeley adaptor comes in a 20ft version (one of the options in the link you provide). We are wondering if that would save us from also needing to purchase extension cables. Any reason not to go with the 20ft iGreeley adaptor (we are connecting the Renogy 100w suitcase to the Zamp port)? thanks!
Hi,
No reason not to, and a good idea!
Dear SA,
I plan on purchasing a VanLeigh Ambition 5th wheel within the next two months. The 5th wheel comes with a 5.5K generator, three 15K BTU A/C units. As well as the mired of other current consumers.
My problem is, the 5.5K generator won’t meet my needs for boon docking. The next Onan generator is a 7.0K generator that has a 6/7 month backlog. I presently own a Honda EU 7000is generator. My question is, can I have the Honda replace the Onan 7.K generator? Complete with connecting the gas fuel line to the on board gas tank? And inside on/off switch?
Hi,
I don’t have any experience with this unfortunately, sorry.
Jesse, I just stumbled onto your site and in hopes you can answer a “novice” question when it comes to solar panel use. We have a pop up trailer with Zamp port. I read your info as to the polarity, etc. My question is this; I have a small 25 watt panel. Mainly saw it as not much more that trickle charger. I usually connect directly to battery with alligator clips during the day. Is this running the risk of overcharging?
Hi,
If the panel was 1-5W I would say no, but I think a 25W panel could definitely overcharge your battery unless you have a very large battery. I would buy a small charge controller if I were you.
Hi, I’m planning on purchasing a power station (either a Bluetti or Ecoflow). Either option will come with a solar panel (200w or 400w, respectively) and I was wondering if I could also use said panels for my RV’s zamp ready solar port. I understand that I would need a charge controller either way. Are there specific measurements I should check for (wattage, voltage, amperage, etc.)? Thank you!
Hi,
First you need to make sure the Zamp port can handle the amperage. There should be a sticker by the port that mentions the max amperage, or it should say in the manual included with your camper. After that, you just need to make sure the charge controller you buy supports the working voltage of the panel. A 200W panel would require at least a 15A charge controller to not waste any power, and a 400W panel a 30A controller.
Hello,
Thank you for the article. I have purchased an Eco Flow generator and solar panels. After I had bought the setup, I learned that my aliner pop-up trailer has a zamp connection. My question is, is there a way to connect the Eco Flow panels to my trailer without purchasing a new Zamp unit? Also, I want to get an extension cord so the panels can be set away from the trailer and still be connected. Any recommendations?
Thank you for your time.
Hi,
Yes, it’s likely that there is a way. What is the model number of your solar panels?
Hi, I have just purchased a tent trailer with a zamp solar connection.
We already have a jackery explorer 500 and a solar saga 100 panel.
Is there any way to take advantage of the zamp connection?
Thanks in advance
Hi,
Yes, you can connect the Jackery solar panel to the Zamp solar port. You have to connect a solar charge controller between the panel and the Zamp port though, because it needs to regulate the power before it is sent to the battery.
I have written an article on this specific topic over on the Camping Nerd, you can find that article by clicking here.
